Product Overview:

XLPE Insulated Power Cable for rated Voltage 0.6/1kV;XLPE Insulated Power Cable for rated Voltage3.6/6kV-26/35kV

Product standards:

XLPE Insulated Power Cable for rated Voltage 0.6/1kV:

This product complies with GB/T 12706.2-2020 for rated voltaae 1 kV (Um=1.2 kV) extruded insulated power

cables and accessories

Rated valtage 6kV (Um=7.2kV) and 30kV (Um=36kV)cables; GB/T19666-2019 "General Rules for Flame-retardant

and Refractory Wire and Cable or Optical Fiber Cable.

 XLPE Insulated Power Cable for rated Voltage3.6/6kV-26/35kV:

This product refers to GB/T 12706.1-2020 for rated voltages from 1 kV (U.=102 kV) to 35 kV (Um=40.5 kV)

extruded insulated power cables and accessories

scope of application:

XLPE Insulated Power Cable for rated Voltage 0.6/1kV:

Suitable for fixed installation of 0.6kV/1ky extruded insulated power cables in distribution networks or industrial installations. Generally used for indoor, cable trench, and underground direct burial laying the cable can withstand a certain amount of laying traction.

XLPE Insulated Power Cable for rated Voltage3.6/6kV-26/35kV:

Mainly used in urban underground power grids,rail transit,power station outgoing lines,and internal power supply

for industrial and mining enterprises.
